| Make | SHK Instrument Solution |
| Model | CIRTC-20 |
| Range | -20 to 100 °C |
| Resolution | 0.1 °C |
| Control Accuracy | ± 0.1 °C |
| Thermal In Stability | ±0.10 °C |
| Control Accuracy | ± 0.1 °C | Display | LCD |
| Hysteresis | ± 0.05 °C | Control Method | Self-tuned PID controller |
| Stabilization Time/settling time | 10 minutes after set point is achieved | Size (H × W × D) | 340(H) x 145(W) x 290(D) mm |
| Thermal Instability | ±0.10 °C at -20°C, ±0.15 °C at 0°C, ±0.22 °C at 100°C | Weight | 10 Kg |
| Thermal Non-Uniformity Radial | ±0.15 °C at -20°C, ±0.27 °C at 0°C, ±0.31 °C at 100°C | Aperture Emissivity | 0.95 ± 0.02 |
| Cooling Time | 30 Min (Ambient to -25°C) @25°C | Aperture Diameter | 50 mm |
| Heating Time | 15 Min (Ambient to 150°C) @25°C | Operating Conditions | 5°C … 25°C |
| Power Supply | 230 V(AC), 50 Hz | Power Consumption | 300 Watt |
The voltage requirement is 230 V AC, 50 Hz.
The weight of the calibrator is 10 Kg.
The aperture emissivity is 0.95 ± 0.02 and the aperture diameter is 50 mm.
Cooling time is 30 minutes (Ambient to -25°C) @25°C and heating time is 15 minutes (Ambient to 150°C) @25°C.
SHK Instrument Solution is a trusted manufacturer and supplier of advanced calibration instruments based in Indore, India.
